Spitznas HFA Impact Wrench
Prominent & Leading Wholesale Trader from Bengaluru, we offer impact wrench order number: 6 1516 0010 and impact wrench order number: 6 1517 0010.
Impact Wrench Order Number: 6 1516 0010
Request Callback
₹ 10000 / Piece Get Latest Price
Product Brochure
| Drive Size | 3/4 Inch |
| Model | 6 1516 0010 |
| Maximum Torque | 1,700 Nm |
| Weight | 7.4 kg |
| brand | Spitznas |
| Vibration level | 1.1 m/s |
Minimum order quantity: 1 Piece
Universally usable hydraulic impact wrench for closed circuit which also can be driven with HFA emulsion.Operating pressure : 260 bar with hydraulic oil, 300 bar with HFA emulsionEnergy source: Hydraulic/HFA (0,3%)Operating pressure: 180-260 (300 HFA) barSquare drive: 3/4Torque max.: 1.700 NmUnderwater operationUnderground miningATEX: IM2ExhIMbT5
Technical DataORDER NO. 6 1516 0010ATEX Specification IM2ExhIMbT5Energy source Hydraulic/HFA-Emulsion (min. 0,3%)Operating pressure 180-260 (300 HFA) barSquare drive 3/4"Screws up to M30 mmVolume flow 9.5 l/minMax. torque 1,700 NmAdjustable torque 350-1,700 NmDistance center to outer edge 52.50 mmImpacts 1,800 rpmWidth without 2nd handle 104.00 mmHydralic hose connection STECKO-10Hydraulic medium Hydraulic oilHydraulic circuit closed circuitOil filtration ISO-level of purity 20/18/13Temperature of oil -34 up to +82 °CViscosity of oil >13 centistokesNoise level LpA 94.5 dB(A)Noise level LWA 103,5 dB(A)Vibration level 1.1 m/s²Weight 7.4 kgFields of application / branch Energy and pipeline construction; Metal industry and steel construction; Mining; Plant and mechanical construction; Underwater Work
Technical DataORDER NO. 6 1516 0010ATEX Specification IM2ExhIMbT5Energy source Hydraulic/HFA-Emulsion (min. 0,3%)Operating pressure 180-260 (300 HFA) barSquare drive 3/4"Screws up to M30 mmVolume flow 9.5 l/minMax. torque 1,700 NmAdjustable torque 350-1,700 NmDistance center to outer edge 52.50 mmImpacts 1,800 rpmWidth without 2nd handle 104.00 mmHydralic hose connection STECKO-10Hydraulic medium Hydraulic oilHydraulic circuit closed circuitOil filtration ISO-level of purity 20/18/13Temperature of oil -34 up to +82 °CViscosity of oil >13 centistokesNoise level LpA 94.5 dB(A)Noise level LWA 103,5 dB(A)Vibration level 1.1 m/s²Weight 7.4 kgFields of application / branch Energy and pipeline construction; Metal industry and steel construction; Mining; Plant and mechanical construction; Underwater Work
Impact Wrench Order Number: 6 1517 0010
Request Callback
₹ 10000 / Piece Get Latest Price
Product Brochure
| Drive Size | 3/8 Inch |
| Model | 6 1517 0010 |
| Maximum Torque | 3,400 Nm |
| Weight | 9.3 kg |
| brand | Spitznas |
| Vibration level | 14.0 m/s |
| Volume flow | 9.5 l/min |
Minimum order quantity: 1 Piece
Universally usable hydraulic impact wrench for closed circuit which also can be driven with HFA emulsion.Operating pressure : 260 bar with hydraulic oil, 300 bar with HFA emulsionEnergy source: Hydraulic/HFA (0,3%)Operating pressure: 180-260 (300 HFA) barSquare drive: 1"Torque max.: 3,400 NmUnderwater operationUnderground miningATEX: IM2ExhIMbT5
Technical DataORDER NO. 6 1517 0010ATEX Specification IM2ExhIMbT5Energy source Hydraulic/HFA-Emulsion (min. 0,3%)Operating pressure 180-260 (300 HFA) barSquare drive 1"Screws up to M39 mmVolume flow 9.5 l/minMax. torque 3,400 NmAdjustable torque 550-3,400 NmDistance center to outer edge 52.50 mmImpacts 1,200 rpmWidth without 2nd handle 112.00 mmHydralic hose connection STECKO-10Hydraulic medium Hydraulic oilHydraulic circuit closed circuitOil filtration ISO-level of purity 20/18/13Temperature of oil -34 up to +82 °CViscosity of oil >13 centistokesNoise level LpA 102.0 dB(A)Noise level LWA 113,0 dB(A)Vibration level 14.0 m/s²Weight 9.3 kgFields of application / branch Energy and pipeline construction; Metal industry and steel construction; Mining; Plant and mechanical construction; Underwater Work
Technical DataORDER NO. 6 1517 0010ATEX Specification IM2ExhIMbT5Energy source Hydraulic/HFA-Emulsion (min. 0,3%)Operating pressure 180-260 (300 HFA) barSquare drive 1"Screws up to M39 mmVolume flow 9.5 l/minMax. torque 3,400 NmAdjustable torque 550-3,400 NmDistance center to outer edge 52.50 mmImpacts 1,200 rpmWidth without 2nd handle 112.00 mmHydralic hose connection STECKO-10Hydraulic medium Hydraulic oilHydraulic circuit closed circuitOil filtration ISO-level of purity 20/18/13Temperature of oil -34 up to +82 °CViscosity of oil >13 centistokesNoise level LpA 102.0 dB(A)Noise level LWA 113,0 dB(A)Vibration level 14.0 m/s²Weight 9.3 kgFields of application / branch Energy and pipeline construction; Metal industry and steel construction; Mining; Plant and mechanical construction; Underwater Work
X
Product Videos
MC313 Underwater cleaning equipment
Get QuoteMC212 Underwater cleaning equipment
